Product Summary

• Mobile PV systems with mono crystalline flexible solar panels and LiFePO4 battery compartments designed for powering a broad range of appliances. Composed of ultra-thin, light yet impact resistant and highly efficient solar panels and compact, lightweight, weather resistant and long-life battery compartments for ultimate versatility, expandability, portability, weather resistance and durability in business, disaster preparedness, leisure and everyday living.

Applications

• Charging the built-in LiFePO4 battery by sunlight, and powering a broad range of appliances through AC100V pure sine wave (inverter outlet, dust and water proof connectors), DC5V (USB) and DC12V (charge controller terminals, dust and water proof connectors) output. A built-in nightlight function can control DC12V load such as LED light at night and is widely programmable.

AC100V	DC12V

Features

• Light yet impact resistant flexible solar panel with highly efficient mono crystalline solar cells.


• A detachable mil-spec Cordura Nylon shoulder strap and mounting holes with grommets for easy carrying and a variety of mounts.


*Fixing pegs and s-hooks in the above image are sold separately.

• A built-in state-of-the-art LiFePO4 battery with a heat function which starts working at 5ºC and stops at 10ºC ensures a lifespan of more than 4000 cycle. 1.2kWh capacity high enough to power 400W fridges for more than a day, 80W TVs for up to 15 hours or 20W notebook PCs for up to 60 hours.

• An IP67 dust and water proof Pelican Case with a fail-safe automatic pressure equalization valve. Equipped with a retractable extension handle and strong polyurethane wheels with stainless steel bearings.

• A built-in MPPT charge controller with a nightlight function accepts solar panels with up to 100V of Voc and 260W of Pm.

• A LCD monitoring screen indicates the present voltage, present current, capacity, state of charge, remaining time, and error code. Power button can switch the battery between active mode and shelf mode.

• Free "DC Home" App for monitoring power generation, charging/discharging current and SOC of the battery by smartphones available from "App Store" and "Google Play".

• A 1000W pure sine wave DC-AC inverter with 2 AC100V outlets and a DC5V USB receptacle for powering a broad range of appliances.

• The battery can be charged by a 150W accessory AC charger with AC100V-240V, 50/60 Hz input.

• Various solar panels with up to 100V of Voc and 260W of Pm can be connected with MC4 Conversion Cables (sold separately).

• Dust and water proof power supply to appliances with AC100V input with AC100V Output Cables.

• Dust and water proof power supply to appliances with DC12V input with DC12V Output Cables (sold separately).

• 2 input connectors for DC Power Cables (sold separately) to double the output capacity.

• IP68 dust and water proof connectors mating with solar panels, Extension Cables, AC100V Output Cables, DC12V Output Cables, DC Power Cables and MC4 Conversion Cables for weather resistant outdoor installations..

Note

• SG12-M100SPM solar panel is not foldable.

Specifications

Solar Panel	Ref. SG12-M100SPM
Solar cells:	mono crystalline solar cells
Max. power*:	100.0W (18.0V 5.56A)
Open circuit voltage*:	21.6V
Short circuit current*:	6.0A
Operating temperature:	-40 - 80ºC
Dimensions (WXDXH):	975X665X approx. 3mm (excl. protruding parts)
Weight:	approx. 3.0kg (excl. accessories)
Mounting holes:	8mm grommet X 6
Output cable:	3m jacket cable with IP68 dust and water proof connector
Safety features:	a bypass diode
Accessories:	a detachable mil-spec Cordura Nylon shoulder strap

Battery Compartment	Ref. SG12-B100LIM
Built-in battery:	LiFePO4 battery
Nominal capacity**:	1200Wh (12V 100Ah)
Cycle life**:	4000 cycles
Max output:	1000W (AC100V inverter outlet) 2.1A (DC5V USB) 20A (DC12V charge controller terminals) 17A (DC12V dust and water proof connectors)
Operating temperature (charge)***:	-10 - 50ºC
Operating temperature (discharge)***:	0 - 40ºC(AC100V, DC5V USB) -15 - 60ºC (DC12V)
Dimensions (WXDXH):	500X305X457mm
Weight:	approx. 22.0kg (excl. battery charger)
Input/output terminals:	IP68 dust and water proof connector X 1
Output terminals:	IP68 dust and water proof connector X 1 AC100V inverter outlet X 2 DC5V USB receptacle X 1 DC12V charge controller terminals X 1
Safety features:	20A MPPT charge controller 20A fuse for short circuit prevention X 2
Accessories:	1000W pure sine wave DC-AC inverter AC 100 - 240V 120W battery charger AC100V Output Cable

*Panel temperature 25ºC AM1.5 1kW/m2
**0.2C rate at 25ºC 80% DOD
***No freezing

Warranty

1 year

Design and specifications are subject to change without notice.

Operating Instructions Manual for SG12-M100SPM Solar Panel (PDF, 7MB)

Operating Instructions Manual for SG12-B100LIM Battery Compartment (PDF, 4MB)

---

Price in Japan: JPY3,800

Applications

Designed to extend the cable of SG12-M100SPM Solar Panels.

Features

IP68 dust and water proof input connectors for weather resistant connection.

Specifications

Extension Cable	Ref. SG12-CE
Cable length:	7m
Allowable current	17A

---

Price in Japan: JPY4,800

Applications

• Designed to convert MC4 connectors of Various solar panels with up to 100V of Voc and 260W of Pm to IP68 dust and water proof input connectors.

  Features

• IP68 dust and water proof input connectors for weather resistant connection.

Specifications

MC4 Conversion Cable	Ref. VCE12MC4
Cable length:	3m
Allowable current	17A

---

Price in Japan: JPY4,800

Applications

• Dust and water proof power supply to appliances with AC100V input from SG12-B100LIM Battery Compartment.

  Features

• IP68 dust and water proof input connectors for weather resistant connection.

Specifications

AC100V Output Cable	Ref. SG12-COAC100V
Cable length:	5m
Allowable current	17A

---

Price in Japan: JPY2,800

Applications

• Dust and water proof power supply to appliances with DC12V input from SG12-B100LIM Battery Compartment.

  Features

• IP68 dust and water proof input connectors for weather resistant connection.

Specifications

DC12V Output Cable	Ref. SG12-CODC12V
Cable length:	5m
Allowable current	17A

---

Price in Japan: JPY8,800

Applications

• Designed to double the output capacity of SG12-B100LIM Battery Compartment by interconnecting 2 units. 2 cables required to power appliances with power consumption of 200W to 400W. You cannot use DC Power Cables to power appliances with power consumption of over 400W.

  Features

• IP68 dust and water proof input connectors for weather resistant connection.

Specifications

DC Power Cable	Ref. SG12-CP
Cable length:	2m
Allowable current	17A
